ELECTRIC SYSTEM 16000 SERVICE/MAINTENANCE MANUAL
3-10
Published 05-03-17, Control # 228-03
Node 3 — Drum Pumps, Alarms, Sensors, and Accessories
Reference Electrical Schematic A10871, Sheet 1, 7, and 16.
Connector #
Function
Type
Description Test Voltage
CAN Packet
Number
W33 Receptacle — Pressure Senders and Accessories
W33-A Ground Cab Tilt/Rotate Solenoid - Up Ground N/A
W33-B DO-1 Cab Tilt/Rotate Solenoid - Up 0 Volts Off, 24 Volts On CAN25-1-1
W33-C Ground Cab Tilt/Rotate Solenoid - Down Ground N/A
W33-D DO-2 Cab Tilt/Rotate Solenoid - Down 0 Volts Off, 24 Volts On CAN25-1-2
W33-E Ground Rear Rotating Bed Pin Solenoid - Extend Ground N/A
W33-F DO-3 Rear Rotating Bed Pin Solenoid - Extend 0 Volts Off, 24 Volts On CAN25-1-4
W33-G Ground Rear Rotating Bed Pin Solenoid - Retract Ground N/A
W33-H DO-4 Rear Rotating Bed Pin Solenoid - Retract 0 Volts Off, 24 Volts On CAN25-1-8
W33-J Ground Boom Hinge Pin Solenoid - Extend Ground N/A
W33-L NS-2 Node Select Jumper to Ground 0 Volts (with Jumper) N/A
W33-N Ground Boom Hinge Pin Solenoid - Retract Ground N/A
W33-P DO-6 Boom Hinge Pin Solenoid - Retract 0 Volts Off, 24 Volts On CAN25-1-32
W33-R DO-5 Boom Hinge Pin Solenoid - Extend 0 Volts Off, 24 Volts On CAN25-1-16
W33-T DI-3 Super Charge Pressure Switch 0 Volts Off, 24 Volts On CAN45-1-4
W33-U 24 Volts Super Charge Pressure Switch 24 Volts Nominal N/A
W33-g Ground Swing Left Pressure Sender Ground N/A
W33-h Ground Jumper to Node Select Ground N/A
W33-m Ground Swing Right Pressure Sender Ground N/A
W33-n 24 Volts Swing Left Pressure Sender 24 Volts Nominal N/A
W33-p AI-7 Swing Left Pressure Sender 1 V at 0 psi, 5 V at 7,000 psi
CAN5-6
1
W33-r AI-8 Swing Right Pressure Sender 1 V at 0 psi, 5 V at 7,000 psi
CAN5-8
1
W33-s 24 Volts Swing Right Pressure Sender 24 Volts Nominal N/A
W34 Receptacle - Drum Pumps and Alarm
W34-A Ground Left Side Swing/Travel Alarm Ground N/A
W34-B DO-11 Left Side Swing/Travel Alarm 0 Volts Off, 24 Volts On CAN25-2-4
W34-C Ground Accessory Proportional Relief Solenoid Ground N/A
W34-D DO-12 Accessory Proportional Relief Solenoid 0 Volts Off, Variable Volts On CAN25-2-8
W34-E Ground Pump 4 Control (Drum 1/Drum 2) Ground N/A
W34-F DO-13 Pump 4 Control (Drum 1/Drum 2)
See
Table 3-2, page 3-6
CAN25-2-16
W34-G Ground Pump 4 Control (Drum 1/Drum 2) Ground N/A
W34-H DO-14 Pump 4 Control (Drum 1/Drum 2)
See
Table 3-2, page 3-6
CAN25-2-32
W34-J Ground Pump 3 Control (Drum 4/Drum 5) Ground N/A
W34-K Ground Pump 6 Control (Drum 2/Drum 1) Ground N/A
W34-L Ground Pump 6 Control (Drum 2/Drum 1) Ground N/A
W34-M DO-17 Pump 6 Control (Drum 2/Drum 1)
See
Table 3-2, page 3-6
CAN25-3-1
W34-N Ground Pump 3 Control (Drum 4/Drum 5) Ground N/A
W34-P DO-16 Pump 3 Control (Drum 4/Drum 5)
See
Table 3-2, page 3-6
CAN25-2-128
W34-R DO-15 Pump 3 Control (Drum 4/Drum 5)
See
Table 3-2, page 3-6
CAN25-2-64
To Next Page
