INTRODUCTION 16000 SERVICE/MAINTENANCE MANUAL
1-8
Published 05-03-17, Control # 228-03
Right Side and Front
Item Description
1 Jacking Cylinder Pads
2 Primary Fuel Filter/Water Separator
3 Coolant Filter
4 Ether Starting Aid Canister
5 Node 5 Controller
6 Air Cleaner Service Indicator
7 Engine Air Cleaner
8 Engine Node 0
9 Clutch Handle
10 Battery Disconnect Switch
11 Engine Oil Filter
12 Fuel Filter, Secondary
13 Swing Motor (2)
14 Swing Gearbox (2)
