16000 SERVICE/MAINTENANCE MANUAL ELECTRIC SYSTEM
3
Jib Node 21 — Block-Up, Load Pin, And Wind Speed
Reference Electrical Schematic A10871, Sheet 1, 11 and 21.
1
Packet number depends on specific attachment used.
Connector #
Function
Type
Description Test Voltage
CAN Packet
Number
J1 Receptacle – CAN In (From Jib Butt) N/A
J211-A 24 Volts CAN Bus System 24 Volts Nominal N/A
J211-B AI-NS Node Select AI-NS Node Select Jumper to GND N/A
J211-C CANH CAN High Wire Transmission N/A N/A
J211-D Ground CAN Bus System Ground N/A
J211-E Ground Node Select Ground to AI-NS Ground N/A
J211-F CANL CAN Low Wire Transmission N/A N/A
J2 Receptacle – Upper Block Up N/A
J212-A 24 Volts Block Up Limit Luffing/Fixed Jib Upper Pt. 24 Volts Nominal N/A
J212-B DI-2 Block Up Limit Luffing/Fixed Jib Upper Pt. 0 Volts Off, 24 Volts On
CAN86-6-64
1
J3 Receptacle – Lower Block Up N/A
J213-A 24 Volts Block Up Limit Luffing Jib Lower Point 24 Volts Nominal N/A
J213-B DI-1 Block Up Limit Luffing Jib Lower Point 0 Volts Off, 24 Volts On
CAN86-6-128
1
J4 Receptacle – CAN Out N/A
J214-A 24 Volts CAN Bus System 24 Volts Nominal N/A
J214-C CANH CAN High Wire Transmission N/A N/A
J214-D Ground CAN Bus System Ground N/A
J214-E DI-ID Last Node Terminating Plug 24 Volts Nominal N/A
J214-F CANL CAN Low Wire Transmission N/A N/A
J8 Wind Speed Indicator N/A
J218-A AI-3 Wind Speed Sensor 0 to 8 Volts DC N/A
J218-B Ground Wind Speed Sensor Ground N/A
Jib Angle Indicator N/A
Wire 1 Ground Jib Angle Indicator Ground N/A
Wire 2 Signal Jib Angle Indicator Variable 0 to 5 Volts N/A
Wire 3 5 Volts Jib Angle Indicator 5 Volts Nominal N/A
