Manitowoc 16000 User Manual

Reference Only
Manitowoc Published 05-03-17, Control # 228-03 3-21
16000 SERVICE/MAINTENANCE MANUAL ELECTRIC SYSTEM
3
W76-m 24 Volts Right Wheel Steering Encoder 24 Volts Nominal N/A
W76-n EC-1A Left Wheel Steering Encoder
1.2 or 3.2 Volts Not Moving,
2.2 Volts Moving
CAN50-2
2
W76-p EC-1B Left Wheel Steering Encoder
1.2 or 3.2 Volts Not Moving,
2.2 Volts Moving
CAN50-2
2
W76-r EC-2A Right Wheel Steering Encoder
1.2 or 3.2 Volts Not Moving,
2.2 Volts Moving
CAN50-2
3
W76-s EC-2B Right Wheel Steering Encoder
1.2 or 3.2 Volts Not Moving,
2.2 Volts Moving
CAN50-2
3
1
Lower four bits can be multiplied by 5 or 10 depending on the sender, then divided by 16 for an estimation of the sender
voltage.
Number in the indicated bank should increment in positive direction and decrement in negative direction with item rotation.
