ELECTRIC SYSTEM 16000 SERVICE/MAINTENANCE MANUAL
3-18
Published 05-03-17, Control # 228-03
W66-C Ground Load Hoist (Drum 1) Left Side Motor Control Ground N/A
W66-D DO-8 Load Hoist (Drum 1) Left Side Motor Control
See Table 3-2, page 3-6
CAN26-1-128
W66-E Ground Load Hoist (Drum 1) Right Side Motor Control Ground N/A
W66-F DO-9 Load Hoist (Drum 1) Right Side Motor Control
See
Table 3-2, page 3-6
CAN26-2-1
W66-G Ground Load Hoist (Drum 1) Min. Bail Limit Switch Ground N/A
W66-H DO-10 Load Hoist (Drum 1) Min. Bail Limit Switch 0 Volts Off, 24 Volts On CAN26-2-2
W66-J DI-8 Load Hoist (Drum 1) Min. Bail Limit Switch 0 Volts Off, 24 Volts On CAN47-1-128
W66-K NS-1 Node Select 1 Jumper to Ground 0 Volts (with Jumper) N/A
W66-L NS-2 Node Select 2 Jumper to Ground 0 Volts (with Jumper) N/A
W66-U Ground Jumper to Node Select Ground N/A
W66-W Ground MAX-ER Strut Position Sensor Ground N/A
W66-X 24 Volts MAX-ER Strut Position Sensor 24 Volts Nominal N/A
W66-Z Ground Load/Luffing (Drum 3) Motor Speed Sensor Ground N/A
W66-e AI-13 MAX-ER Strut Position Sensor 0 Volts Off, 24 Volts On
CAN11-2
1
W66-g 24 Volts Load Hoist (Drum 1) Motor Speed Sensor 24 Volts Nominal N/A
W66-j Ground Load Hoist (Drum 1) Motor Speed Sensor Ground N/A
W66-m 24 Volts Load/Luffing (Drum 3) Motor Speed Sensor 24 Volts Nominal N/A
W66-n EC1A Load Hoist (Drum 1) Motor Speed Sensor
1.2 or 3.2 Volts Not Moving,
2.2 Volts Moving
CAN46-2
2
W66-p EC1B Load Hoist (Drum 1) Motor Speed Sensor
1.2 or 3.2 Volts Not Moving,
2.2 Volts Moving
CAN46-2
2
W66-r EC2A Load/Luffing (Drum 3) Motor Speed Sensor
1.2 or 3.2 Volts Not Moving,
.2 Volts Moving
CAN46-2
2
W66-s EC2B Load/Luffing (Drum 3) Motor Speed Sensor
1.2 or 3.2 Volts Not Moving,
2.2 Volts Moving
CAN46-2
2
1
Lower four bits can be multiplied by 5 or 10 depending on the sender, then divided by 16 for an estimation of the sender
voltage.
Number in the indicated bank should increment in positive direction and decrement in negative direction with item rotation.
Connector #
Function
Type
Description Test Voltages
CAN Packet
Number
