Manitowoc Grove TMS9000-2 Series User Manual

OPERATING CONTROLS AND INDICATORS TMS9000-2 OPERATOR MANUAL
3-52 Published 02-21-2019, Control # 611-05
Telescoping semi-automation menu
The telescoping semi-automation menu is where you select
the amount of telescoping for each boom section.
NOTE: Important information about the use of the semi-
auto mode is found on page 4-70.
FIGURE 3-48
8882-6
1
2
3
4
5
6
7
8
9
Item Description Refer to
1 Telescopic sections display page 3-103
2
Pre-selection individual
telescopic sections
page 3-103
3
Current telescope status
display
page 3-103
4 Input confirmation page 3-35
5
Telescoping permitted/not
permitted display
6
Locking status telescopic
section display
7
Telescoping cylinder length
display
8
Locking status telescoping
cylinder display
9 Main boom length display
