OPERATING CONTROLS AND INDICATORS TMS9000-2 OPERATOR MANUAL
3-80 Published 02-21-2019, Control # 611-05
1)
For Service personnel only, not suitable for external
devices, e.g. mobile phone
Item Description Refer to
1
RCL Display Module
(RDM)
Overview of the RCL start
menu
Overview of the RCL menu
groups
page 3-83
2 Jog dial page 3-34
3
Service/diagnosis
connection
1)
4
Exiting the menu/input
mode
page 3-128
5 Selector buttons page 3-35
6 Tare Button/Function page 3-134
6.1 Tare Button/Function page 3-134
7 RCL Overload Indication page 3-129
8 Lighting Sensor page 3-89
9 Input confirmation page 3-35
10 Changing menus page 3-33
11 Switch display page 3-35
12 RCL Warning Indication page 3-129
13
Display temperature
warning display
page 3-35
