ELECTRICAL SYSTEM
General Specifications
Type of System .......................................................................................................... 12 Volt, Negative Ground
Batteries...................................................................... One or Two 12 Volt, Low Maintenance Hybrid Batteries
Connected in Parallel, DIN Type 60527,
Taper Post Terminals
Alternator.................................................................................................................................. 12 Volt, 95 Amp
12 Volt, 120 Amp. for Tractors with Heated Seat Cushions
Voltage Regulator.................................................................................... 12 Volt, Solid State, Part of Alternator
Starter Motor, with Solenoid Switch........................................................................................... 12 Volt, 2.8 kW
Accessory Connectors
7 Terminal Electrical Outlet ..................................................................... Equipped for Directional Turn Lamps,
Stop lamps, Tail Lamps
Single Auxillary Socket
(next to 7 Terminal Socket) ........................................................................................................ 12 Volt Power
for Implements with Circuit Protection
3 Pin Cab Connector................................................................................... 12 Volt Power Through Key Switch
and also Direct with Ground for
Implement Controllers and Monitors
TYPE
SAE (COLD CRANKING
CAPACITY)
IEC DIN
AMPERE
HOURS
RESERVE
CAPACITY
629 1000 Amps 670 Amps 600 Amps 170 320 mins
644 660 Amps 440 Amps 400 Amps 95 180 mins
664 770 Amps 515 Amps 465 Amps 105 210 mins
648 810 Amps 545 Amps 490 Amps 120 220 mins
