Operation
159
5
Variable Flow Controls
If there is too much restriction in the implement
cylinders or other attachments, the restriction can
cause a back pressure in the remote hydraulic
valve which will cause the remote hydraulic lever
on the console to return to the neutral (kick out)
position before the cylinder reaches the full
stroke.
If this condition occurs decrease the amount of
fluid going to the implement.
NOTE: It is normal for the remote hydraulic
control lever to return to the neutral position
when the cylinders reach the full stroke.
Flow Rate Adjustment
Use the variable flow controls to increase or
decrease the rate of flow of hydraulic fluid to the
remote hydraulic couplers.
This can be done either at the Hydraulic Valve,
DP97A151
Or by using the Optional Cab Controls*.
*
Subject to availability
MD05A001
