Tyres, Wheels, Ballasting
174
MFD FRONT WHEEL TREAD WIDTHS
IMPORTANT: The steering stops on the axle must
be installed in the correct position for the tread
width and tyre size being used.
One Piece Wheels
One piece wheels are not adjustable and can
only be interchangeable between each side of
the axle.
MH04E019
1830 mm (72 in)
RIM IN
MH04E020
1930 mm (76 in)
RIM OUT
WARNING: When servicing or making
adjustments to the tractor with one set of
wheels supported on a stand, NEVER
attempt to rotate the wheel either by hand
or by starting the engine. This could propel
the tractor of the stands. Either support all
wheels off the ground or disconnect the
front axle drive shaft.
