Operation
IV
Hitch Operation
STEP 1
Lower the lower links and set for Rigid or Float
application, as required.
STEP 2
Attach the implement to the hitch. Make sure the
correct category implement is attached. A category
indication is stamped on each lower link.
Make sure the claws on the front hitch engage with
the implement and the latches lock.
MH04N042
STEP 3
MD05F037
Move the relevant remote control to raise or lower
the hitch as required.
Optional Equipment
Remote Hydraulic Couplers
MD04N043
IMPORTANT: The front remote couplers are
supplied from one of the rear remote valves. DO
NOT use both the front and the corresponding
rear remote couplers at the same time.
To Next Page
