Operation
III
Lower Links
The lower links have three positions. When
changing the position of the lower links, support the
links when removing the retaining pins.
Both lift links must be set in the same position.
Raise the hitch to maximum height before adjusting
the lower links.
Rigid Position
MD04N040
For operation with no vertical movement, install the
retaining pins in the rear hole.
Float Position
MD04N039
For operation with vertical float, independently of
each other, install the retaining pins in the front
hole.
Stored Position
MD04N041
Top Link
MD04N038
When not being used store the Top Link as shown
above.
When operating on the public highway without
equipment attached always store the top link
correctly.
