MCCORMICK MTX Series - Page 265

Technical Specfications
257
9
40 km/h Transmission (Creeper Speeds)
To convert to M.P.H. multiply km/h values by 0.62.
CREEPER SPEEDS
IN KILOMETERS PER HOUR
POWERSHIFT SPEED-RANGE AUTO SPEED GEAR
REAR TYRE SIZES and
(INDEX RADIUS mm)
16.9R34
480/70R34
540/65R34
(745)
12.4R42
(765)
600/65R34
18.4R34
(770)
540/65R38
16.9R38
(795)
18.4R38
(820)
580/70R38
20.8R38
(855)
18.4R42
(870)
20.8R42
(918)
1-1 1 0.37 0.38 0.38 0.39 0.40 0.42 0.43 0.45
CREEPER FORWARD SPEEDS
2-1 2 0.44 0.45 0.46 0.47 0.49 0.51 0.52 0.54
3-1 3 0.55 0.56 0.56 0.58 0.60 0.63 0.64 0.66
4-1 4 0.68 0.69 0.70 0.72 0.74 0.78 0.79 0.82
1-2 5 0.69 0.71 0.71 0.74 0.76 0.79 0.80 0.84
2-2 6 0.83 0.85 0.86 0.89 0.91 0.95 0.97 1.01
3-2 7 1.03 1.05 1.06 1.09 1.13 1.18 1.20 1.25
4-2 8 1.27 1.30 1.31 1.36 1.40 1.46 1.48 1.54
1-3 9 1.37 1.41 1.42 1.47 1.51 1.58 1.61 1.67
2-3 10 1.66 1.70 1.71 1.77 1.82 1.90 1.93 2.01
3-3 11 2.05 2.10 2.11 2.18 2.25 2.35 2.39 2.49
4-3 12 2.53 2.60 2.62 2.71 2.79 2.91 2.96 3.08
1-4 13 2.67 2.75 2.76 2.85 2.94 3.07 3.12 3.25
2-4 14 3.22 3.31 3.33 3.44 3.54 3.70 3.76 3.91
3-4 15 3.98 4.09 4.11 4.25 4.38 4.57 4.65 4.83
4-4 16 4.93 5.06 5.10 5.26 5.43 5.66 5.76 5.99
1-1R 1R 0.42 0.44 0.44 0.45 0.47 0.49 0.50 0.52
CREEPER REVERSE SPEEDS
2-1R 2R 0.51 0.53 0.53 0.55 0.56 0.59 0.60 0.62
3-1R 3R 0.63 0.65 0.65 0.67 0.70 0.73 0.74 0.77
4-1R 4R 0.78 0.80 0.81 0.84 0.86 0.90 0.91 0.95
1-2R 5R 0.80 0.82 0.82 0.85 0.88 0.92 0.93 0.97
2-2R 6R 0.96 0.99 0.99 1.02 1.06 1.10 1.12 1.17
3-2R 7R 1.19 1.22 1.23 1.27 1.31 1.36 1.39 1.44
4-2R 8R 1.47 1.51 1.52 1.57 1.62 1.69 1.72 1.79
1-3R 9R 1.59 1.63 1.64 1.70 1.75 1.83 1.86 1.93
2-3R 10R 1.92 1.97 1.98 2.04 2.11 2.20 2.24 2.33
3-3R 11R 2.37 2.43 2.45 2.53 2.61 2.72 2.77 2.88
4-3R 12R 2.93 3.01 3.03 3.13 3.23 3.37 3.43 3.56
13R 3.08 3.16 3.18 3.29 3.39 3.54 3.60 3.74
