Renogy ONE Core Energy Monitoring System
The Renogy ONE Core is a factory-installed, CAN bus-integrated energy monitoring and
smart control system in the
XT12HR OGE Off-Grid Extreme Trailer. It provides real-time
power system monitoring, remote access, and smart automation through:
• Built-in touchscreen display for local control.
• Renogy DC Home App for remote monitoring via Wi-Fi or Bluetooth.
• Renogy ONE Portal for web-based access.
• Smart Home Automation for controlling lights, security, and climate.
With ONE Connect 2.0 technology, the system continuously tracks battery status, solar
input, inverter power, and shore power, while offering wireless device pairing for Renogy
Bluetooth, Zigbee, and RS-485 smart accessories. Over-the-air (OTA) updates ensure the
system stays up to date.
The Renogy ONE Core is
pre-configured via the CAN bus
for direct communication with
Renogy lithium
battery, solar charge controllers, and the REGO 3000W HF Inverter-Charger
. No additional wiring is
required.
Powering On/Off
• To turn ON: Press and hold the Power Button for 5 seconds until the display
activates.
• To turn OFF: Press and hold the Power Button for 5 seconds until the screen
shuts down.
The Renogy ONE Core powers on automatically when the RV’s 12V power system is
active.
System Display & Monitoring
The Renogy ONE Core touchscreen provides real-time data for managing your
trailer’s electrical system, including:
• Battery Status: Displays charge percentage, voltage, and current flow from the lithium battery bank.
• Solar Input: Monitors real-time power generation from the Renogy MPPT Solar Charge Controller.
• Inverter Status: Indicates whether the Renogy REGO 3000W HF Inverter-Charger is supplying AC power.
• Shore Power: Shows voltage and current input from a 30A shore power connection.
• DC Load Usage: Displays the power consumption of all 12V appliances and circuits.
