Section 3 - Screen Overview and Operation
Page 36 90-8M0070299 eng MAY 2012
Screen Display
Name
Description Screen
Peak Performance
Displays engine RPM and speed, along with the peak RPM
and speed.
27212
Trim
Displays engine RPM, speed, gallons per hour, and trim level.
27213
Tab
Displays engine RPM, speed, gallons per hour, and the
position of the tabs (Zeus and inboard applications only).
34267
Demand and Load
Displays engine RPM, load, and throttle percentages.
27115
Boost
Displays engine supercharger boost pressure for Verado
engines.
NOTE: The boost screen can be turned on or off under the
"Setup" menu by selecting "Settings" and then "Preferences."
27214
