Section 3 - Screen Overview and Operation
90-8M0070299 eng MAY 2012 Page 37
Screen Display
Name
Description Screen
Troll Control
Displays engine RPM and allows the operator to set troll
speed below 1000 RPM.
27215
Cruise Control
Allows the operator to set engine RPM above 1000 RPM on
specific power packages.
27119
Smart Tow
Allows the operator to control the speed of acceleration from
idle to set cruise speed on a DTS engine (not available on all
versions of VesselView).
27216
Transmission
Displays engine RPM with transmission gear temperature and
pressure.
27117
Intake
Displays engine RPM, intake temperature, and boost.
27116
