QX-830 Compact Industrial Scanner User’s Manual A-11
Appendices
Serial Trigger Stop Character <K230,stop character>
Processing Timeout <K245,processing timeout>
Scan Speed <K500,scan speed>
Maximum Element <K502,maximum element>
Automatic Gain Control
<K504,gain level,AGC sampling mode,AGC minimum,AGC
maximum>
Symbol Detect Status / Transition
Counter
<K505,symbol detect status,transition counter>
Scan Width Enhance <K511,status>
AGC Tracking <K520,tracking>
Laser Setup
<K700,laser on/off,laser framing status,laser on position,laser off
position,laser power>
Configuration Database
Number of Active Indexes <K252,number of active indexes,number of database cycles>
Configuration Database
<K253,index,gain,AGC mode,tracking,unused,unused,unused,
framing status,laser on position,laser off position,laser power,
background color>
Switch Timing <K254,switch mode,time>
Symbologies
Quiet Zone <K450,quiet zone status>
Background Color <K451,background color>
Symbol Ratios <K452,Code 39,Codabar,Interleaved 2 of 5>
Composite <K453,symbology status,separator status,separator>
AIAG
<K454,status,ID1,status1,ID2,status2,ID3,status3,ID4,status4,
ID5a,ID5b,ID5c,status5, ID6,status6,ID7,status7,ID8, status8,
ID9,status9,ID10,status10,ID11,status11,ID12,status12>
Depth of Field Enhance <K456,
DOF Enhance mode>
Code 39
< K470, status,check character status,check character output status,
large intercharacter gap,fixed symbol length status,fixed symbol
length,full ASCII set>
Codabar
<K471,status,start/stop match status,start/stop output status,
large intercharacter gap,fixed symbol length status,fixed symbol
length,check character type,check character output status>
Interleaved 2 of 5
< K472, status,check character status,check character output status,
symbol
length 1,symbol length 2,guard bar,range mode status>
UPC/EAN
<K473,mode,EAN status,supplementals
status,separator status,
separator
character,supplementals type,UPC-E as UPC-A>
Code 128 / EAN 128
<K474,status,fixed symbol length status,fixed symbol length,
EAN status,output format,application record separator status,
application
record separator character,application record brackets,
application record padding,separation factor>
Code 93 <K475,mode,fixed symbol length status,symbol length>
PDF417
<K476,status,scan line limit,fixed symbol length status,fixed
symbol length,decode at end of read cycle>
Pharmacode
<K477,status,fixed bar count status,fixed bar count,minimum bar
count,bar width mode,direction,fixed threshold value>
