A-12 QX-830 Compact Industrial Scanner User’s Manual
Serial Commands
DataBar Omnidirectional (RSS-14) <K482,status>
DataBar Limited (RSS Limited) <K483,status>
DataBar Expanded (RSS Expanded) <K484,status,fixed symbol length status,fixed symbol length>
MicroPDF417
<K485,status,scan line limit,fixed symbol length status,fixed
symbol length>
Symbol Reconstruction
<K496,symbol reconstruction redundancy,symbol reconstruction
effort>
I/O Parameters
Calibration Options
<K521,unused,video,scan speed,laser power,laser framing,
symbology>
Serial Verification
<
K701,
serial command echo status, serial command beep status,
control/hex
output>
Beeper <K702,status>
Quality Output
<K704,quality output separator, decodes per trigger status,
decode direction output>
Symbol Data Output
<K705,symbol data output status, when to output symbol data,
symbology identifier status>
Read Duration Output <K706,status,separator>
No Read Message <K714,status,message>
Bad Symbol Message <K715,status,message>
No Symbol Message <K716,status,message>
Input 1 <K730,input mode,active state>
Green Flash LED
<
K750,
green flash mode,unused,green flash duration>
Status Indicators <K751,status,bar graph,I/O 1,I/O 2>
Symbol Position Output <K758,scan status,separator>
Database Identifier Output <K759,status,separator character>
EZ Button <K770,status,default on power-on>
EZ Button Modes <K771,single beep,two beeps,three beeps,four beeps>
Auto Framing Options
<K773,laser framing>
Trend Analysis Output 1
<K780,trend analysis mode,number of triggers,number to output
on,decodes per trigger>
Trend Analysis Output 2
<K781,trend analysis mode,number of triggers,number to output
on,decodes per trigger>
Trend Analysis Output 3
<K782,trend analysis mode,number of triggers,number to output
on,decodes per trigger>
Diagnostics Output 1
<K790,high temperature,service unit,unused,laser current high,
laser current low,low temperature>
Diagnostics Output 2
<K791,high temperature,service unit,unused,laser current high,
laser current low,low temperature>
Diagnostics Output 3
<K792,high temperature,service unit,unused,laser current high,
laser current low,low temperature>
Output 1 Parameters <K810,output on,output state,pulse width,output mode>
Output 2 Parameters <K811,output on,output state,pulse width,output mode>
Output 3 Parameters <K812,output on,output state,pulse width,output mode>
