MIMAKI UJF-7151 plus User Manual

1-6
Chapter 1 Before Use
Carriage
A print head for printing, LED UV device, and a light pointer in
the print head cover are mounted on the carriage.
About table
It is necessary to adjust the table height depending on the media thickness because various media can be set for
printingprinting.
The specification of each table is as less:
About tap position
The table and the vacuum table on which the media set have the M4 tap (47 positions) of the size below respectively.
Table
UJF-7151 plus UJF-7151 plusII
Acceptable media
weight
*1
*1. If you put a heavier thing than specified, the quality image may be degraded.
10kg and less 30kg and less
Vacuum function Yes Yes
Table movable area 0 to 153mm 0 to 153mm
Media thickness 0 to 153mm 0 to 153mm
• Although tap holes are open except the tap position in the printing ( ), they are necessary in the production process.
Therefore, please do not use them.
• We may change the position except specified tap holes ( ) without prior notice.
