3-13
Chapter 3 Setup
3
2
2
2
Setting of FAN MODE
You can set whether the vacuum function to fix the media
set on the table is performed automatically or you perform
it manually.
The factory default is “AUTOMATIC”.
1
Press the
(MENU)
(3 times)
key in LOCAL.
• SETUP MENU will be displayed.
2
Press the
(>>)
.
3
Press to select “FAN MODE” ,
and press the key.
4
Press to select a set value, and
press the key.
• Set value : AUTOMATIC/ MANUAL
5
Press the key several times to
end the setting.
Setting of AUTO CLEANING
Sets the automatic cleaning operation for the head
performed before printing or after printing.
1
Press the
(MENU)
(3 times)
key in LOCAL.
• SETUP MENU will be displayed.
2
Press the
(>>)
.
3
Press to select “AUTO
CLEANING” , and press the key.
4
Press to select a set value, and
press the key.
• Set value :
BEFORE PRINT / AFTER PRINT / OFF
5
Press the key several times to
end the setting.
Setting of PRINT FLUSHING LEVEL
When using a clear acrylic jig and so on, the ink may
splash on the print result as the ink on the nozzles
thickens due to stray light.
If this happens, increase the flushing amount before
printing to prevent ink from splashing.
1
Press the
(MENU)
(3 times)
key in LOCAL.
• SETUP MENU will be displayed.
2
Press the
(<<)
.
3
Press to select “PRINT
FLUSHING” , and press the key.
4
Press to select a set value, and
press the key.
• Set value : Levrel 0 to 3
5
Press the key several times to
end the setting.
• When the "FAN MODE" is set to "AUTO" and
AUTO CLEANING (P.3-13) is set to "AFTER
PRINT", the vacuum function is automatically
turned off before AUTO CLEANING.
• If you set it to "AFTER PRINT", also set the work
change (P.3-12) to "ON".
• During the AUTO CLEANING of "AFTER PRINT",
you can switch the vacuum function ON and OFF
by pressing the [FUNC1] key.
• For the amount of ink consumed for each level,
see the following.
Level 0 : 0.003 cc
Level 1 : 0.007 cc
Level 2 : 0.015 cc
Level 3 : 0.024 cc
