Chapter 2 Basic Operation
5
Check result of printing.
• When the result is normal, finish the operation.
(P.2-8)
• When the result is abnormal, execute head
cleaning. ( P.2-7)
Execution of head
cleaning
When a correct pattern is not obtained in the test printing,
perform the head-cleaning. As for the head cleaning, the
following 3 types are available.
1
Press the (
TEST PRINT/CLEANING)
in the local.
2
Press to select the
"CLEANING
"
and press the key.
3
Select the head, set execution/non-
execution of cleaning, and press the
key.
(1) Select the head with [][].
(2) Select execution/non-execution of the head
cleaning with [][].
• Select execution of cleaning for every head.
Execute Cleaning : Head color being set
is displayed.
Not Execute Cleaning : “ - ” is displayed.
4
Press to select the cleaning
type, and press the key.
• Cleaning is started.
• When the cleaning is completed, a mode is
returned to the local mode.
5
Execute test printing and check the result
of the test printing.
• Repeat cleaning and test printing until normal
result is obtained.
Normal pattern
Abnormal patterns
Nozzle drop out
Many lines are missing.
Nozzle missing
The lines are missing as if the teeth are lost.
Deflection
The distance between the lines is narrowing or
double lines are formed.
normal
To be used if ten odd numbers of the lines
are missing when the test pattern is made.
Wiping will be performed.
hard
To be used when the missing of the lines
does not improve with the “normal” cleaning.
soft To be used when the lines are curved.
To Next Page
