MIMAKI UJF-7151 plus User Manual

Chapter 3 Setup
3-30
Printing Check Flow
Nozzle check is conducted according to the following flow at the start of printing.
Printing Operations at “Nozzle Missing” Judgment and Error Occurrence
 When judged to be “Nozzle Missing”  Printing is stopped.
 When error occurs during nozzle check  Printing is stopped and “Printing Check” is automatically turned
OFF. After recovering from the error, set “Printing Check” once
again.
• Turn the “Printing Check” setting ON to be enabled.
• Only perform RETRY COUNT and Printing Check settings when the settings are enabled.
1
nozzle check  Judgment
2
3
Recovery operation 
nozzle check  Judgment
4
Retry  Judgment
Printing Check  Judgment
Detects missing nozzles.
If more missing nozzles than “Judgement
Condition” are detected after the nozzle check,
cleaning is performed and nozzle check is
conducted again.
5
Nozzle Missing judgment
If more missing nozzles than A are eventually
detected, continued printing will be deemed
impossible and printing will stop.
If more missing nozzles than “Judgement
Condition” are detected after the recovery
operation, the recovery operation is conducted
again.
• If the “RETRY COUNT” setting is configured to 1 or more,
this becomes effective.
Nozzle recovery is automatically conducted
following nozzle check and recovery operation.
• Turn the “Printing Check” setting ON to be enabled.

MIMAKI UJF-7151 plus Specifications

General

Print Technology	UV LED Inkjet
Max Print Resolution	1200 x 1200 dpi
Maximum Media Weight	10 kg
Media Weight	Up to 10 kg
Interface	USB 2.0, Ethernet
Operating Environment Humidity	35 - 65% RH (Non-condensing)
Printhead	Piezoelectric
Media Size	710 x 510 mm
Ink Type	UV Curable Ink
Ink Colors	C, M, Y, K, White, Clear
Ink Types	LUS-120
Power Supply	AC 100-240 V
Operating Environment Temperature	20 - 30 °C
Maximum Print Area	710 x 510 mm (27.9" x 20")
