SETUP MENU table
• For each setting item below, you can set it so that the machine may operate according to the value specified when you
printed from your RIP software in the connected host PC.
• Set Item : FEED COMP./INK LAYER/Logical Seek/REFRESH
• When you operate the machine according to the contents specified with the RIP software, set each item to “Host” when
registering this machine type. When you set it other than “Host”, the machine operates according to the machine setting.
• For the specifying method with the RIP software, refer to the operation manual of the RIP software.
Function name
Set value
*1
*1. The underlined value is set at the time of purchase.
Outline
FEED COMP.( P.3-10) -9999 ~ 0 ~ 9999
Used to print a pattern for correcting a media-feeding rate and
correct it.
LOGICAL SEEK( P.3-10) ON
/ OFF Sets the scan movable area during printing.
INK LAYERS ( P.3-11) 1
~ 9 Sets the number of layers in which ink is to be applied.
REFRESH LEVEL ( P.3-11) 0 ~ 1
~ 3 Sets the interval of refresh performed during printing.
PRIORITY ( P.3-11)
ALL HOST
/ALL PLOT/
INDIVIDUAL
Selects the priority from the settings on this machine (PLOT) or
the settings on a computer (HOST) about the following items.
Items: FEED COMP./INK LAYER/Logical Seek/REFRESH
UV MODE ( P.3-12)
ON
/OFF/NO PRINT/
Calibration
Sets the UV irradiation during printing.
WORK CHANGE ( P.3-12) ON / OFF
Set whether to return to the local mode or keep the remote
mode after online drawing.
FAN MODE ( P.3-13) AUTOMATIC
/MANUAL Sets the vacuum function.
AUTO CLEANING ( P.3-13)
BEFORE PRINT
/ AFTER
PRINT / OFF
Sets the automatic cleaning operation for the head performed
before printing or after printing.
PRINT FLUSHING LEVEL ( P.3-13) 0
~ 3 Sets the flushing amount before printing.
MAPS4 ( P.3-14) MANUAL / AUTO
Perform setting to reduce stripes between passes.
Misregistration
adjust
(P.3-15)
Feed Direction
-8 ~ 0
~ 8
Correct the mis-registration occurs at printing the color/spot
color version.
Feed Direction
Reverse Print -2.00 ~ 0.55
~ 2.00mm
LT mode ( P.3-15) ON / OFF
When LUS - 120 ink is printed on a media (synthetic leather)
where may bending and stretching occurs, and then left in a
low - temperature environment (20 ° C or less), the printed
surface may crack. By specifying this mode, cracks can be
reduced.
To Next Page
