20 - 2 BeneVision N Series Patient Monitor Operator’s Manual
20.2 CCO/SvO
2
Safety Information
• Because the alarm limits of the relevant measured parameters can be set on this monitor, the alarms
of these parameters may be different from those on the Vigilance II/Vigileo/EV1000/HemoSphere
monitor. Please pay special attention to the alarms on the Vigilance II/Vigileo monitor.
• The CCO/SvO
2
monitoring is not intended for neonatal patients.
• Observe the operator’s manuals of Vigilance II/Vigileo/EV1000/HemoSphere monitor to configure
settings and to connect the monitor to the patient.
• This patient monitor gives disconnection alarms when it is disconnected from the Vigilance II/
Vigileo/EV1000/HemoSphere monitor. These alarms may be delayed.
20.3 CCO Display
The monitor displays CCO parameters from the Vigilance II monitor, Vigileo monitor, or EV1000 monitor. The CCO
parameters area varies with different monitoring mode and monitors. You can select the desired parameters to
be displayed. For the configuration of the parameters to be displayed, see 20.7.3Setting Parameters for Display.
20.4 SvO
2
/ScvO
2
Display
The monitor displays either SvO
2
or ScvO
2
parameters from the Vigilance II/Vigileo/EV1000/HemoSphere
monitor. SvO
2
numeric area and ScvO
2
numeric area cannot display simultaneously. The display depends on the
setting of the Vigilance II/Vigileo/EV1000/HemoSphere monitor.
20.5 Connecting the Device
The CCO/SvO
2
cable is used to connect this monitor to the Vigilance II/Vigileo/EV1000/HemoSphere monitor.
20.5.1 CCO/SvO2 Cable
The following figure shows the CCO/SvO
2
cable.
