26 - 2 BeneVision N Series Patient Monitor Operator’s Manual
To connect the external device, follow this procedure:
1. Insert a BeneLink module into the SMR.
2. Connect the ID adapter that matches the external device to the BeneLink module with an RJ45 connecting
cable.
3. Connect the ID adapter to the external device:
◆ For the TCM monitor, connect the ID adapter to the serial port (COM port) of the TCM monitor with
Mindray type C serial port adapting cable (PN: 009-001769-00) and an interface cable provided with
the TCM monitor.
◆ For the SenTec Digital Monitor, connect the ID adapter to the serial port (COM port) of the SenTec
Digital Monitor with Mindray type C serial port adapting cable (PN: 009-001769-00).
4. Put a label indicating device name to the RJ45 connecting cable at the end near the BeneLink module.
When the BeneLink module is connected to several external devices, you can easily recognize the devices
with these labels.
5. Turn on both monitors.
26.4 tcGas Parameters
The following table lists tcGas parameters provided by different monitors:
NOTE
• On the SenTec Digital Monitor it is possible to disable/enable the parameters to be monitored. For
tcpO
2
monitoring an OxiVenT™ Sensor and activated PO
2
-option are required. If the SenTec Digital
Monitor is operated in neonatal mode, SpO
2
and PR are not supported.
26.5 Activating the tcGas Alarm Sound
To activate the tcGas alarm sound, follow this procedure:
1. Select the tcGas numeric area to enter the +tcGas menu.
2. Set Alarm Sound to On.
After the tcGas alarm sound is activated, the patient monitor gives sound prompts for the alarms of the tcGas
monitor.
(4) ID Adapter (5) Type C serial port adapting cable
TCM CombiM/TCM4/TCM5
monitor
TCM TOSCA monitor TCM40 monitor SenTec Digital Monitor
Primary
parameters
Secondary
parameters
Primary
parameters
Secondary
parameters
Primary
parameters
Secondary
parameters
Primary
parameters
Secondary
parameters
tcpCO2,
tcpO2
Power,
Tsensor
tcpCO2 SpO
2
, PR,
Power,
Tsensor
tcpCO2,
tcpO2
SpO
2
, PR,
Power,
Tsensor
tcpCO2,
tcpO2
SpO
2
, PR,
Power,
Tsensor
