25 - 6 BeneVision N Series Patient Monitor Operator’s Manual
25.8.2 Setting the Apnea Alarm Delay
The monitor will alarm if the patient has stopped breathing for longer than the previously set apnea time. To
change the delay time of the apnea alarm, follow this procedure:
1. Select the numeric area or waveform area of Paw, Flow or Vol to enter the RM menu.
2. Select the Alarm tab.
3. Enter the password if required.
4. Set Apnea Delay.
• The respiration monitoring does not recognize the cause of apneas. It only indicates an alarm if no
breath is detected when a preadjusted time has elapsed since the last detected breath. Therefore, it
cannot be used for diagnostic purposes.
25.8.3 Setting RR Source
To set the RR (respiration rate) source, follow this procedure:
1. Select the numeric area or waveform area of Paw, Flow or Vol to enter the RM menu.
2. Select the Setup tab.
3. Set RR Source.
When the current RR source does not have valid measurement, the system will automatically switch RR Source to
Auto.
25.8.4 Changing the Wave Sweep Speed
To set the sweep speed of Paw, Flow, and Vol waveforms, follow this procedure:
1. Select the numeric area or waveform area of Paw, Flow or Vol to enter the RM menu.
2. Select the Setup tab.
3. Set Speed.
25.8.5 Changing the Wave Scale
To set the scale of Paw, Flow, and Vol waveforms, follow this procedure:
1. Select the numeric area or waveform area of Paw, Flow or Vol to enter the RM menu.
2. Select the Setup tab.
3. Set Paw Scale, Flow Scale, or Vol Scale
25.8.6 Setting the Ambient Temperature
To set the ambient temperature, follow this procedure:
1. Select the numeric area or waveform area of Paw, Flow or Vol to enter the RM menu.
2. Select the Setup tab.
3. Set Atmosphere Temp.
25.8.7 Setting the Ambient Humidity
To set the ambient humidity, follow this procedure:
1. Select the numeric area or waveform area of Paw, Flow or Vol to enter the RM menu.
2. Select theSetup tab.
3. Set Relative Humidity.
