BeneVision N Series Patient Monitor Operator’s Manual A - 11
A.15 Measurement Specifications
The adjustable range of alarm limits is the same with the measurement range of signals unless otherwise
specified.
A.15.1 ECG Specifications
ECG
Standards Meet standards of IEC 60601-2-27 and IEC 60601-2-25
Lead set 3-lead: I, II, III
5-lead: I, II, III, aVR, aVL, aVF, V
6-lead: I, II, III, aVR, aVL, aVF, Va, Vb
12-lead: I, II, III, aVR, aVL, aVF, V1 to V6
ECG standard AHA, IEC
Display sensitivity 1.25 mm/mV (×0.125), 2.5 mm/mV (×0.25), 5 mm/mV (×0.5), 10 mm/mV (×1),
20 mm/mV (×2), 40 mm/mV (×4), Auto, less than 5% error
Sweep speed 6.25 mm/s, 12.5 mm/s, 25 mm/s, 50 mm/s, less than 5% error
Bandwidth (-3dB) Diagnostic mode:
Monitor mode:
Surgical mode:
ST mode:
High Freq Cut-off (for 12-lead
ECG analysis)
0.05 to 150 Hz
0.5 to 40 Hz
1 to 20 Hz
0.05 to 40 Hz
350 Hz, 150 Hz, 35 Hz, or 20 Hz, selectable
Common mode rejection ratio Diagnostic mode:
Monitor mode:
Surgical mode:
ST mode:
>90 dB
>105 dB (with notch filter on)
>105 dB (with notch filter on)
>105 dB (with notch filter on)
Notch filter 50/60 Hz
Monitor, surgical, and ST mode: notch filter turns on automatically
Diagnostic mode and High Freq Cut-off: notch filter is turned on/off manually
Differential input impedance ≥5 M
Input signal range ±8 mV (peak-to-peak value)
Accuracy of signal reproduction Use A and D methods based on IEC 60601-2-25 to determine frequency
response.
Electrode offset potential tolerance ±500 mV
Lead-off detection current Measuring electrode: <0.1 A
Drive electrode: <1 A
Input offset current ≤0.1 A, (drive lead≤1A)
Defibrillation protection Enduring 5000V (360 J) charge without data loss or corruption
Baseline recovery time: <5 s (after defibrillation)
Polarization recovery time: <10 s
Defibrillation energy absorption: ≤10% (100 load)
Patient leakage current <10 uA
Calibration signal 1mV (peak-to-peak value) ±5%
ESU protection Cut mode: 300 W
Coagulate mode: 100 W
Recovery time: ≤10 s
In compliance with the requirements in clause 202.6.2.101 of IEC 60601-2-27
Pace Pulse
