3 - 20 BeneVision N Series Patient Monitor Operator’s Manual
• The setting of Screen Size takes effect only after the remote screen restarts.
3.15.6 Selecting a Different Monitor for nView
To switch the monitor you want to view remotely, follow this procedure:
1. Select the Main Menu quick key → from the System column select nView Tool.
2. Select the Select Device tab.
3. Select Refresh Device List.
4. From the monitor list, select the desired monitor.
5. From the popup dialog box, select OK to restart the remote screen.
3.15.7 Restarting a remote screen
If you changed the settings for a remote screen, restart it for the changes to take effect. To do so, follow this
procedure:
1. On the remote screen, select the Main Menu quick key → from the System column select nView Tool to
call out the nView Tool.
2. Select the Remote Screen tab.
3. Select Restart Remote Screen.
3.15.8 Closing remote screens
Remote screens automatically close if the monitor is turned off or disconnected from the network for one
minute. To manually close remote screens, follow this procedure:
1. On the remote screen,select the Main Menu quick key → from the System column select nView Tool to
call out the nView Tool.
2. Select the Remote Screen tab.
3. Select the Exit Remote Screen. This will exit all remote screens.
If you started multiple remote screens, you can close any of them separately.
â– If the remote screen is not in full screen, select the close button at the top right corner. From the popup
dialog box, select Close This Screen.
â– If the remote screen is in full screen, select the Windows key to call out the taskbar. Right-click the remote
screen icon and select Close Window. From the popup dialog box, select Close This Screen.
(1) the amplitude ECG waveform corresponding to one centimeter
(2) the speed of the ECG waveform corresponding to one centimeter
