BeneVision N Series Patient Monitor Operator’s Manual 34 - 17
34.6.3 Reviewing ECG Summary
From the ECG 24h Summary window, you can review corresponding trends and events.
■ Select the Heart Rate area to review HR graphic trends.
■ Select the Max ST/Min ST area to review the current ST reference and ST graphic trends.
■ Select the Pace area to review historic pace events.
■ Select the QT area to review QT/QTc graphic trends.
■ Select the Arrhythmia area to review arrhythmia statistics.
■ Select Full Disclosure to review ECG full disclosure waveforms. For more information, refer to 32.2.8Full
Disclosure Review Page.
34.7 Pace View
Pace View helps you view pace pulse details, including amplitude, width, shape, and duration.
NOTE
• The Pace View function is intended for patients with implanted pacemaker. It is available only when
Paced is set to Yes.
• A license is required for the Pace View function.
34.7.1 Accessing Pace View
Access Pace View by any of the following ways:
■ Select the Pace View quick key.
■ From the ECG menu, select the Pacer tab → Pace View.
■ Select the Main Menu quick key → from the CAA column select Pace View.
34.7.2 Viewing the Current Pace Pulse
From the Current page of Pace View, view the details of the current pace pulse.
■ Select the Pace Magnifier tab, view the pace pulse duration.
■ Select the Spike Magnifier tab, view the amplitude, width, and shape of the pace pulse.
From Pace View, you can perform the following operations:
■ Select Refresh to obtain the current pace pulse
■ Select Save as Event to save the current pace as an event.
■ Select Lead to define the lead you want to view.
■ Select the left and right arrows to select pace pulse you want to view.
34.7.3 Viewing Historic Pace Events
To view the details of historic pace events, including pacer not paced, pacer not captured, choose either of the
following ways:
■ From Pace View select the Event tab. For more information, see 34.7.1Accessing Pace View.
■ From ECG 24h Summary select the Pace area. For more information, see 34.6.1Viewing the ECG 24h
Summary.
Select the desired event, and then select Detail to view pace pulse details of the selected event.
You can also view historic pace events from the Review menu. To do so, follow this procedure:
1. From the Review menu, select the Events tab.
2. Select the desired event, and then select Detail.
3. Select Pace View.
