BeneVision N Series Patient Monitor Operator’s Manual D - 7
Note: XX represents an IBP label, for example PA, CVP, FAP, P1, and so on.
D.2.8 C.O. Technical Alarm Messages
D.2.9 ScvO
2
Technical Alarm Messages
D.2.10 ICG Technical Alarm Messages
XX Disconnected High C The liquid way is disconnected from the patient,
or the three-way valve is open to the air. Check
the connection of the liquid way, or check the
valve is open to the patient. If the alarm persists,
contact your service personnel.
Alarm message Default priority
Indication on
alarm reset
Cause and solution
Alarm message Default priority
Indication on
alarm reset
Cause and solution
TB Sensor Off Low A Check the sensor connection and reconnect the
sensor.
TI Sensor Off Low A Check the sensor connection and reconnect the
sensor.
Alarm message Default priority
Indication on
alarm reset
Cause and solution
ScvO2 High Signal Low C Check the sensor and reposition the catheter.
Recalibrate the sensor.
ScvO2 Low Signal Low C Check the sensor and reposition the catheter.
Recalibrate the sensor.
ScvO2 Excess Light Low C Avoid excessively strong backlight.
Optical Module
Disconnected
Low A Connect the optical module.
Unsupported CeVOX
version
Low A The module version is not compatible with the
system. Contact your service personnel.
Disconnected from
Vigilance
Low A The Vigilance monitor is disconnected. Check the
connection between the CCO/SvO
2
module and
the Vigilance monitor.
Disconnected from
Vigileo
Low A The Vigileo monitor is disconnected. Check the
connection between the CCO/SvO
2
module and
the Vigilance monitor.
Alarm message Default priority
Indication on
alarm reset
Cause and solution
ICG Cable Error Low C ICG cable is not calibrated or calibration failed.
Replace the cable.
To Next Page
