8-10
T
M80 Telemetry Monitor Service Manual
3.
R
emove the g
rounding
copper foil and four M1.6x2.4 cap head screws on the
main control board, open the card fasteners on the FPC socket, a
nd remove
the two FPCs.
Grounding
copper foil
R
Remove the FPC of the L
CD
screen from the main contr
ol
board socket
Fo
u
r
M1.6
×
2.4
cap head
scre
ws
175
177
