9-10 TM80 Telemetry Monitor Service Manual
NO. P/N Description
1 / Gasket of top housing
2 / AC light pipe
3 / Pan head screw M4X8
4 / Charger-main-support
5 / Spring, EMI
6 / ST3.3X8 screw
7 / Charger Connector Board PCBA
8 / Charger Charge main Board PCBA
9 / AC power socket & connecting cable
10 / Charger bottom housing(SY)
11 / FOOT-VS
12 / Screw hole cover 1
13 / Screw hole cover 2
14 / Screw, Pan Head W/Washer Phillips M3X6
15 / POWER SUPPLY BOARD 15V 63W
16 / Thermal Pad
17 / AC-DC insulating trip
18 / Indicator label
19 / Light pipe of central charger
20 / Charger top housing
21 / The host label(FDA)
22 / Main board wire
23 / Battery interface board wires
