Chapter 4: USB Setup Interface
32
Standard Diagnostic Object [SmallDiag; ObjId=24]
ManufacturerExceptionDetailWarn Inst see Status - ManufacturerExceptionDetailWarn
ProductCode Inst see Identity - ProductCode
SoftwareRevision Inst see Identity - SoftwareRevision
HardwareRevision Inst see Identity - HardwareRevision
FullScale Inst calculated fullscale for 1179 Objects
RunHours Inst see System - RunHours
InternalTemp Inst temperature in [°C] (in 10E-4) steps; see System - InternalTemp
ValvePosition Inst
0..100% (in 10E-4 steps´)
0% = valve is closed
100% = valve is in purge position (full open)
see Valve - ValvePosition
TimeToCal Inst see System - TimeToCal
SetDefault Func Reset object to default values
Identity Object [Identity; ObjId=25]
Name
Par.
Type
Description
DeviceType Inst MFC,MFM
ProductCode Inst MF1
Manufacturer Inst MKS Instruments
Model Inst MF1..
SerialNumber Inst G123456G20
SoftwareRevision Inst TBD
HardwareRevision Inst TBD
InterfaceType Inst [ANALOG, PB, DNET, RS485, ....]
SensorType Inst [MEMS, AMETAL]
SpecialNr Inst Device Special Number
CalDate Inst Date of calibration
UserTag Inst any 32 character string
SvnNr Inst actual SVN software project number
SibSNr Inst SIB Serial Number
DibSNr Inst DIB Serial Number
DibFwVersion Inst DIB Firmware Version
CdcName Inst
Cdc Name (default: device serial)
Can used to assign a device part on the USB bus.
CdcRevision Inst CDC Revision for InstrumentBrowser
SetDefault Func Reset object to default values
Password Object [Password; ObjId=26]
Name
Par.
Type
Description
SetPasswordDevice Inst Set new Device Password
UnlockDevice Inst Unlock device for user defined setup; (CalTable...)
UnlockFactory Inst Unlock device for factory setup
UnlockDeviceStatus Inst [0=locked; 1=unlocked]
