Chapter 4: USB Setup Interface
31
Full Output 1179 Object [FullSend; ObjId=22]
Purge Inst see SmallSend - Purge
OverTemperature Inst see SmallSend - OverTemperature
ValveDriveAlarm Inst see SmallSend - ValveDriveAlarm
CalibrationRecommended Inst see SmallSend - CalibrationRecommended
Uncalibrated Inst see SmallSend - Uncalibrated
ControllerError Inst see SmallSend - ControllerError
MemoryFailure Inst see SmallSend - MemoryFailure
UnexpectedCondition Inst see SmallSend - UnexpectedCondition
ThermalMassFlowRate Inst see SmallSend - ThermalMassFlowRate
InternalTemperature Inst see SmallSend - InternalTemperature
ValveDriveLevel Inst see SmallSend - ValveDriveLevel
FlowTotalized Inst
totalized flow
in FlowUnit (in 10E-1 steps)
i.e. min. 298 days for a 500 range
SetDefault Func Reset object to default values
Standard Setup 1179 Object [SmallSetup; ObjId=23]
Name
Par.
Type
Description
BaseUnit Inst Display in base unit; (base unit =>FlowUnit of CalTable Object)
OperationMode Inst see Analog - OperationMode
ZeroGain Inst 5% .. 200% full scale (in 1¤-4 steps); see Meter - ZeroGain
ZeroOffset Inst -5% .. +5% full scale (in 1¤-4 steps); see Meter - ZeroOffset
TripPointHigh Inst -10% .. + 120% full scale (in 1¤-4 steps); see SigProc - TripPointHigh
TripPointLow Inst -10% .. + 120% full scale (in 1¤-4 steps); see SigProc - TripPointLow
GasCorrection Inst (in 1E-4 steps) see Meter - GCF
DefaultTable Inst see SigProc - DefaultTable
TripPointHigh2 Inst -10% .. + 120% full scale (in 1¤-4 steps); see SigProc - TripPointHigh2
TripPointLow2 Inst -10% .. + 120% full scale (in 1¤-4 steps); see SigProc - TripPointHigh2
FilterSettling Inst 0.0 .. 1000.0 in [sec] (in 1E-4 steps); see SigProc - FilterSettling
SoftStartRate Inst 0.0 .. 3600.0 in [sec] (in 1E-4 steps); see Controller - FilterSettling
TimeToCal Inst see System - TimeToCal
CalDate Inst see Identity - CalDate
UserTag Inst see Identity - UserTag
SetDefault Func Reset object to default values
Standard Diagnostic Object [SmallDiag; ObjId=24]
Name
Par.
Type
Description
CommonExceptionDetailAlarm Inst see Status - CommonExceptionDetailAlarm
DeviceExceptionDetailAlarm Inst see Status - DeviceExceptionDetailAlarm
ManufacturerExceptionDetailAlarm Inst see Status - ManufacturerExceptionDetailAlarm
CommonExceptionDetailWarn Inst see Status - CommonExceptionDetailWarn
DeviceExceptionDetailWarn Inst see Status - DeviceExceptionDetailWarn
