MKS MF1 - Page 47

Chapter 4: USB Setup Interface
47
Gas Calibration Object [CalTable]
32 32 1..n 53 Pointer RWPD uint8 1 1 20 STNV
32 32 - 100 SetDefault WPF cmd - - - -
32 32 - 101 StoreSensorValue W cmd - - - -
Controller Calibration Object [ControllerTable]
Obj. Slot Inst. Param. Name Access Type Default Min. Max. Store
33 161 0 0 ObjId R uint8 33 - - -
33 161 0 1 ObjName R char[12] ControllerT - - -
33 161 0 2 Length R uint16 13 - - -
33 161 0 3 NrOfInstances R uint8 16 - - -
33 161 0 4 ActInst RW uint8 1 1 16 -
33 33 1..n 0 Instance R uint8 1 1 16 STNV
33 33 1..n 1 ControllerP RWPD float 1 0 100000 STNV
33 33 1..n 2 ControllerI RWPD float 0 0 100000 STNV
33 33 1..n 3 ControllerD RWPD float 0 0 100000 STNV
33 33 - 100 SetDefault WPF cmd - - - -
Acceleration Setup Object [AccelSetup]
Obj. Slot Inst. Param. Name Access Type Default Min. Max. Store
34 162 0 0 ObjId R uint8 34 - - -
34 162 0 1 ObjName R char[12] AccelSetup - - -
34 162 0 2 Length R uint16 66 - - -
34 162 0 3 NrOfInstances R uint8 16 - - -
34 162 0 4 ActInst RW uint8 1 1 16 -
34 34 1..n 0 Instance R uint8 1 1 16 STNV
34 34 1..n 1 SetpointFilter RWPD float 0 0 1000 STNV
34 34 1..n 2 StartAddGain RWPD float 0 1 1000 STNV
34 34 1..n 3 StartMinFlow RWPD float 0 0 1000 STNV
34 34 1..n 4 TempCoefOffset RWPD float 0 0 1000 STNV
34 34 1..n 5 TempCoefGain RWPD float 0 0 1000 STNV
34 34 1..n 6 SpeedupGain RWPD float 0 0 100000 STNV
34 34 1..n 7 SpeedupTau RWPD float 0 0 100000 STNV
34 34 1..n 8 SpeedupGainFlowInc RWPD float -0.27 -1000 1000 STNV
34 34 1..n 9 SpeedupGainTempInc RWPD float 0 -1000 1000 STNV
34 34 1..n 10 SpeedupTauTempInc RWPD float 0 -1000 1000 STNV
34 34 1..n 11 TempValveOffset RWPD float 0 -1000 1000 STNV
34 34 1..n 12 FltType RWPD long 0 0 2 STNV
34 34 1..n 13 Flt1StabFac RWPD float 0 0 1000 STNV
34 34 1..n 14 Flt1ReactFac RWPD float 1 0 1 STNV
34 34 1..n 15 Flt2Boarder RWPD float 0 0 1000 STNV
34 34 1..n 16 Digits RWPD uint8 5 2 6 STNV
34 34 1..n 17 AddValveOffset RWPD float 0 0 131072 STNV
34 34 - 100 SetDefault WPF cmd - - - -
