Chapter 4: USB Setup Interface
48
Gas Conversion Object [GasConv]
Obj. Slot Inst. Param. Name Access Type Default Min. Max. Store
35 163 0 0 ObjId R uint8 35 - - -
35 163 0 1 ObjName R char[12] GasConv - - -
35 163 0 2 Length R uint16 28 - - -
35 163 0 3 NrOfInstances R uint8 16 - - -
35 163 0 4 ActInst RW uint8 1 1 16 -
35 35 1..n 0 Instance R uint8 1 1 16 STNV
35 35 1..n 1 ID RW char[8] N2 - - STNV
35 35 1..n 2 CalTableInstance RW uint8 1 1 16 STNV
35 35 1..n 3 ControllerSetupInstance RW uint8 1 1 16 STNV
35 35 1..n 4 AccelSetupInstance RW uint8 1 1 16 STNV
35 35 1..n 5 GasCorrectionFactor RW float 1 0.1 20 STNV
35 35 1..n 6 FullScale R float 100
-
1,00E+038
1,00E+038 STNV
35 35 1..n 7 MinDisplay RWPD float 0
-
1,00E+038
1,00E+038 STNV
35 35 1..n 8 MaxDisplay RWPD float 100
-
1,00E+038
1,00E+038 STNV
35 35 - 100 SetDefault WPD cmd - - - -
Device Status Object [Status]
Obj. Slot Inst. Param. Name Access Type Default Min. Max. Store
36 164 0 0 ObjId R uint8 36 - - -
36 164 0 1 ObjName R char[12] Status - - -
36 164 0 2 Length R uint16 27 - - -
36 164 0 3 NrOfInstances R uint8 1 - - -
36 164 0 4 ActInst RW uint8 1 1 1 -
36 36 1..n 0 ExceptionByte R uint8 0 0 255 STNV
36 36 1..n 1 CommonExceptionDetailAlarm R uint8 0 0 255 NSTNV
36 36 1..n 2 DeviceExceptionDetailAlarm R uint8 0 0 255 NSTNV
36 36 1..n 3 ManufacturerExceptionDetailAlarm R uint8 0 0 255 NSTNV
36 36 1..n 4 CommonExceptionDetailWarn R uint8 0 0 255 NSTNV
36 36 1..n 5 DeviceExceptionDetailWarn R uint8 0 0 255 NSTNV
36 36 1..n 6 ManufacturerExceptionDetailWarn R uint8 0 0 255 NSTNV
36 36 1..n 7 AlarmEnable RW uint8 0 0 1 STNV
36 36 1..n 8 WarningEnable RW uint8 0 0 1 STNV
36 36 1..n 9 EepromChecksumFailCnt R uint16 0 0 65535 STNV
36 36 1..n 10 FlashChecksumFailCnt R uint16 0 0 65535 STNV
36 36 1..n 11 StartUpCnt R uint16 0 0 65535 STNV
36 36 1..n 12 LowVoltageCnt R uint16 0 0 65535 STNV
36 36 1..n 13 WpdCnt R uint16 0 0 65535 STNV
36 36 1..n 14 WpfCnt R uint16 0 0 65535 STNV
36 36 1..n 15 WdSibCnt R uint16 0 0 65535 STNV
