Chapter 4: USB Setup Interface
49
Device Status Object [Status]
36 36 1..n 16 SibDibComExcepCnt R uint16 0 0 65535 STNV
36 36 1..n 17 WdDibCnt R uint16 0 0 65535 STNV
36 36 - 100 SetDefault WPF cmd - - - -
Analog Interface Object [Analog]
Obj. Slot Inst. Param. Name Access Type Default Min. Max. Store
37 165 0 0 ObjId R uint8 37 - - -
37 165 0 1 ObjName R char[12] Analog - - -
37 165 0 2 Length R uint16 10 - - -
37 165 0 3 NrOfInstances R uint8 1 - - -
37 165 0 4 ActInst RW uint8 1 1 1 -
37 37 1..n 0 OperationMode RW uint:1 0 0 1 STNV
37 37 1..n 1 FullscaleVoltage RW float 5 5 10 STNV
37 37 1..n 2 ZeroscaleVoltage RW float 0 0 2 STNV
37 37 - 100 SetDefault WPF cmd - - - -
Fieldbus Interface Object [Fieldbus]
Obj. Slot Inst. Param. Name Access Type Default Min. Max. Store
38 166 0 0 ObjId R uint8 38 - - -
38 166 0 1 ObjName R char[12] Fieldbus - - -
38 166 0 2 Length R uint16 12 - - -
38 166 0 3 NrOfInstances R uint8 1 - - -
38 166 0 4 ActInst RW uint8 1 1 1 -
38 38 1..n 0 Address R uint8 1 0 127 STNV
38 38 1..n 1 SoftwareAddress RW uint8 126 0 127 STNV
38 38 1..n 2 MaxBaudrate R long 12000000 9600 12000000 STNV
38 38 1..n 3 CyclTlgInputObjectId RW uint8 20 0 45 STNV
38 38 1..n 4 CyclTlgOutputObjectId RW uint8 21 0 45 STNV
38 38 1..n 5 Config R long 0 0 0 STNV
38 38 - 100 SetDefault W cmd - - - -
38 38 - 101 RestartFieldBus W cmd - - - -
Com Interface Object [ComIfc]
Obj. Slot Inst. Param. Name Access Type Default Min. Max. Store
39 167 0 0 ObjId R uint8 39 - - -
39 167 0 1 ObjName R char[12] ComIfc - - -
39 167 0 2 Length R uint16 17 - - -
39 167 0 3 NrOfInstances R uint8 1 - - -
39 167 0 4 ActInst RW uint8 1 1 1 -
39 39 1..n 0 Address R uint8 0 0 125 STNV
39 39 1..n 1 SoftwareAddress RW uint8 126 0 127 STNV
