Motala MC2000 - Preparation

Threshold – Installation instruction
© 2013 Motala Hissar AB 3 (6) IQ56-11 Rev: B
5. INSTALLATION
The threshold is divided in two parts, one inner part (stainless steel) and one outer part
(aluminum profile).
5.1 Preparation
5.1.1 Finished floor
Make sure the floor outside the lift
is finished. Otherwise the inner part
of the threshold has to be adjusted
in height by a fitter after the floor is
finished.
For alternative installation method if
the floor is not finished at the time
of the lift installation see 3.1 and
5.1.2.
5.1.2 If the floor is not finished.
1. Note! If the floor is not
finished, do not make marks
for screws on the outer part of
the threshold as described in
5.2.1. Get the finished floor
level height from the builder
and fix the inner part of the
threshold at the right height
(use a spirit level). (1) Then,
when the floor is finished the
builder must slide on the outer
part of the threshold on to the
inner part of the threshold. (2)
Drill 3 holes through the
threshold to fix the outer part
to the floor. Use countersunk
screws or flat head screws to
fix the threshold to the floor.
The builder must supply the
proper screw for the finished
floor and make sure the fitting
looks neat and proper!
