Motala MC2000 - Fix the platform; Finalize the fixing of the platform

Platform floor – Installation instruction
© 2013 Motala Hissar AB 7 (8) IQ56-15 Rev: (B)
4.2.3 Fix the platform
Adjust position so that the holes in
the sledge and fixings of the
platform floor is aligned.
Fix the platform with screws in the
holes below the first screw, use 2x
100179. Tighten the screws.
4.2.4 Finalize the fixing of the
platform
Raise the platform above the
mechanical blocking device and
activate it.
Finalize the fixing of the platform by
fitting the remaining two screws on
each side, use 2x 100179. Tighten
the screws.
