MOTALA MC2000 Automatic door operator ST1300
clamp protection
Instruction
© 2012 Motalahissar AB 4 (6) IQ56-18
Rev: -
5. Preperation
This instruction shows the installation of a automatic door operator clamp protection
part no. 731886 on a left-hinged door. For right-hinged door use automatic door
operator clamp protection part no. 731960.
Lower engine cabinet
If there is a engine cabinet at the
same side as the clamp
protection is to be fitted it has to
be lowered 10mm.
