Motala MC2000 - Lift the platform into the well; Connect the winch to the platform lifting eye

Platform floor – Installation instruction
© 2013 Motala Hissar AB 5 (8) IQ56-15 Rev: (B)
4.1.3 Lift the platform into the well
Two persons is needed to lift the
platform into the lift well. Use 2x
lifting tool 731953.
4.1.4 Connect the winch to the
platform lifting eye
Connect the winch hook to the
lifting eye on the platform. Check
that the screws for the lifting eye is
firmly tighten.
