Motala MC2000 - Mount the Platform Frame; Mount the Mechanical Blocking Device

MOTALA MC2000 – Mechanical blocking device
Instruction
© 2012 Motalahissar AB 9 (12) IQ56-03 Rev: B
Mount the platform frame
1. Mount the platform frame
730752, use 8x 100179.
2. See the MC2000 installation
instruction for further important
details on mounting the
platform.
Mount the mechanical blocking
device
1. Mount the mechanical
blocking device 730905, use
6x 102040.
