MOTALA MC2000 – Flip chair on the platform
Instruction
© 2012 Motalahissar AB 4 (6) IQ56-06
Rev: -
4. Installation
Remove the COP
1. Remove the COP to be able to
install the consol for the flip
chair. Refer to document IQ56-04
Updated version of the platform
wall MC2000 installation
instruction.
Fit the consol
1. Fit the consol 731093 by using 2x
100223 in the pre-drilled holes in
the platform wall.
2. Make sure the consol I vertical by
using a spirit level before fitting
the lower part of the consol by
using 3x 100223. (you might have
to mark and drill holes before
fitting the screws in the platform
floor).
