Platform floor – Installation instruction
© 2013 Motala Hissar AB 4 (7) IQ56-16 Rev: -
4. INSTALLATION
4.1 Preparation
Install motor.
4.1.1 Fit the bracket unit
Fit the bracket unit in the 2 pre-
drilled holes in the door frame
under the motor.
4.1.2 Adjust bracket unit
Adjust bracket unit and tighten
screws. Make sure there is a small
gap between bracket and brake to
avoid vibration noise.
