MC2000 – Assembly Instruction Manual
Tools
Tools/Equipment with item numbers can be or-
dered from Motala Hissar AB.
Equipment
MH item
numbe
r
Notes
Sets of dimension sticks, 1480 mm, 1081
m
m, 1181 mm.
705827 For lift well construction, outside dimensions:
depth 1560mm x width 1150 mm/1250mm.
Work platforms, standard set. 705658 For lift well construction. For about three
floo
rs. Extra equipment to be ordered
Drive command box complete with 25 m
ca
ble.
705868 For driving the lift during assembly and test-
ing.
Winch or telpher, min. approx 100 kg. 705867 For lifting guide rails.
Lifting eye bolt with lock, see ill 6 on
page 25.
705826 For lifting guide rails.
Fastening rod (telescopic) 705824 For suspending the winch in the well top.
Chain fixing tool. 701268 To prevent the chain from sliding during as-
sembly.
Glue sprayer. 101428
Structural glue. 100510 Gluing of platform floors.
Grease and lubricating substances. Lubrication of guide rails and lock arms.
Lifting tool (suction cups), 2 pieces 101423 For glass and lift well modules.
Working place illumination
Spirit-level, short, approx, 500 mm
Spirit-level, long, approx, 2000 mm
Measure tape/folding rule, plumb.
Measuring instruments
Tools for electric installation
Jigg saw with long blade “120mm”. For cutting lift well modules “35mm thick”.
Wire shears For cutting wires and wire covers.
Electric screw driver with extender and bits,
ty
pe ph2.
Ratchet with extender and sleeves 13 mm
a
nd 17 mm.
Ring-open-end spanners 7-17 mm.
Plate shears
Riveting tongs
Drill, diameter 3.3, 4.2, 6 and 12 mm For pop rivets and making holes in jointing
r
ods for drive chains.
Hand tools: multi-purpose pliers, screwdriv-
ers, socket wrenches etc.
Hack saw For sawing the joint rod of the drive chain.
Crowbar
