Motala MC2000 - Adjustment

MOTALA MC2000 Manual door closer when headroom
is 1300mm (so-called “half door”)
Instruction
© 2012 Motalahissar AB 5 (6) IQ56-12
Rev: -
Fit door closer
1. Remove the plastic cover and
push the closer 102354 onto the
slider. Fix the closer, use 4x
101528. Put the plastic cover
back on the door closer.
Adjustment
1. Adjust the closer, see
documentation that comes with
the closer.
2. Before leaving the site check
several times that the door closes
nice and smoothly.
3. Installation is complete.
