• Criteria - Criteria can be set according to Input plug-in, symbology, matching string within the data (at the
specified position) and/or data length. Received data must match the defined criteria in order for the data to be
processed.
• Actions - A set of procedures defined to format data. There are four types of actions which are for formatting
cursor movement, data modification, data sending and delay specifications. An action can be defined to send the
first number of characters to the Output plug-in, pad the output data with spaces or zeros, remove spaces in data,
etc.
Configuring ADF Plug-in
Configuring the ADF plug-in consists of creating a rule, defining the criteria and defining the actions.
Procedure:
1
Touch
.
2
Touch
.
3 Touch a DataWedge profile.
4 In Keystroke Output, touch Advanced data formatting.
Figure 61: Advanced Data Formatting Screen
5 Touch the Enable checkbox to enable ADF.
Creating a Rule
Note: By default, Rule0, is the only rule in the Rules list.
Procedure:
1 Touch .
2 Touch New rule.
3 Touch the Enter rule name text box.
4 In the text box, enter a name for the new rule.
5 Touch Done.
6 Touch OK.
76 | DataWedge Configuration
May 2015 | MN000116A02-A
