Kernal Plug-in
• Enable Plugin - Enables logging for this kernal buffer.
• Log path - Specifies the high level log path for storage of all kernal logs. This setting applies globally to all kernal
buffers.
• Kernal Log filename - Specifies the base log filename for this kernal buffer. The current file count is appended to
this name.
• Max Kernal log size - Specifies the maximum size, in kilobytes, of an individual log file.
• Kernal Log interval - Sets the interval, in milliseconds, on which to flush the log buffer to the file.
• Kernal Log file count - Specifies the number of log files to keep and rotate through. Each log file is subject to the
max log size option.
• Output - The kernal plug-in outputs a series of text files in accordance with the configuration. The files contain
the output of the kernal buffer flushed at the specified interval.
Configuration File
RxLogger configuration can be set using an XML file. The config.xml configuration file is located on the
microSD card in the RxLogger\config folder. Copy the file from the device to a host computer using a USB
connection. Edit the configuration file and the replace the .XML file on the device. There is no need to stop and
restart the RxLogger service since the file change is automatically detected.
Enabling Logging
Procedure:
1
Touch .
2
Touch .
3 Touch Start.
4
Touch .
Disabling Logging
Procedure:
1
Touch
.
2 Touch .
3 Touch Stop.
4
Touch .
Extracting Log Files
Procedure:
1 Connect the device to a host computer using an USB connection.
2 Using a file explorer, navigate to the RxLogger folder.
3 Copy the file from the device to the host computer.
4 Disconnect the device from the host computer.
Application Deployment | 135
MN000116A02-A | May 2015
