Listing Volumes
Procedure:
1 Touch Volume List.
2 Touch sdcard to list volumes on the microSD card or internal to list volumes on internal storage.
3 Touch OK. The List of EFS Volumes dialog box appears with all the volumes of the selected storage location.
4 Touch OK.
Unmounting a Volume
Procedure:
1 Touch Unmount Volume.
2 Touch sdcard to list the mounted volumes on the microSD card or internal to list the mounted volumes on
internal storage.
3 Touch OK.
4 Select the volume to un-mount.
5 Touch OK.
Deleting a Volume
Procedure:
1 If the encrypted volume is mounted, unmount it.
2 Touch Delete Volume.
3 Touch sdcard to list the unmounted volumes on the microSD card or internal to list the unmounted volumes on
internal storage.
4 Select the volume to delete.
5 Touch OK.
Encrypting an SD Card
Caution: All data will be erased from the microSD card when this is performed.
Procedure:
1 Touch Encrypt SD card. A warning message appears.
2 Touch Yes. The Key List dialog box appears.
3 Select a key from the list and then touch Ok.
The encryption process begins and when completed, displays a successfully completed message.
Creating an EFS File
When creating an encrypted volume, the parameter information can be imported from a file instead of entering
manually.
Procedure:
1 On a host computer, create a text file.
2 In the text file enter the following:
<Volume Name> <Volume Storage Type> <Key Name> <Mount Path> <Auto Mount> <Volume size>
where:
<Volume Name> = name of the volume
106 | Administrator Utilities
May 2015 | MN000116A02-A
