Figure 40: Vehicle Holder Mounted on Flat Surface
7 Connect the auto charger cable to the MC67 and slide the two locking tabs up to secure the cable cup to the
MC67.
8 Connect the other end to the cigarette lighter socket.
The LED indicator on the right side of the touch screen lights up orange during charging.
Handstrap Replacement
Removal
To remove a handstrap from the MC67:
Caution: Close all running applications prior to replacing the handstrap. The backup battery maintains data
for up to 15 minutes. If replacement takes longer than 15 minutes data may be lost.
Procedure:
1 If the MC67 is in suspend mode, press the red Power button to wake the MC67.
2 Press the red Power button.
The Power Action Key window appears.
3 Tap Safe Battery Swap.
The Data Capture LED lights red.
4 When the LED turns off, remove the handstrap.
Accessories | 51
MN000116A02-A | May 2015
